Linksys MR8300 Frequently Asked Questions

User-added image





1.  What is the Linksys MR8300 Mesh WiFi Router, AC2200, MU-MIMO?

The Linksys MR8300 Mesh WiFi Router, AC2200, MU-MIMO is an intelligent Mesh compatible router which makes it capable to act as a primary node to your Velop system.  It enables you to expand your Wi-Fi by letting you take advantage of the Intelligent Mesh WiFi System that is made for modular nodes.  These work seamlessly together to fit the need of any home and deliver flawless Wi-Fi wherever you want it.  To learn more, click here.

2.  What are the parts of the Linksys MR8300?

The parts of the Linksys MR8300 are:
  • Ports - one power, one Gigabit internet port, four Gigabit ethernet ports
  • Lights
    • Single light indicator on top of the Mesh router
    • Internet and ethernet (1-4) lights on the back panel
  • Button - reset button and a WPS button located on the side of the Mesh router
  • Switch - power switch
To know more, click here.

3.  What are the product features of the Linksys MR8300?

Below are the major product features of the Linksys MR8300:
  • Tri-Band speed up to 2.2 Gbps
  • 802.11ac
  • 2 x 2 simultaneous data streams for stronger, faster performance
  • Intelligent Mesh Technology
  • Beamforming Technology
  • Guest Network
  • Parental Controls
  • Four adjustable antennas (non-detachable)
  • Four Gigabit ethernet ports + one Gigabit internet port

4.  What is the warranty of the Linksys MR8300?

The warranty period is dependent on the country of purchase.  For more information about your device’s warranty, click here.
Hardware WarrantyUS and CanadaUK and EMEA
Linksys MR83001 year2 years

5.  What do the lights on the Linksys MR8300 indicate?

The lights indicate the different status and activities of your Mesh router.  For a detailed description, click here.

6.  Can I plug my USB hard drive or a printer to the USB port on the Linksys MR8300?

No.  Currently the USB port does not support USB devices, the USB port is for future expansion.

7.  Is the Linksys MR8300 compatible with other Velop products?

Yes, the Linksys MR8300 is compatible with all the Velop products.  The Linksys MR8300 must be the primary node while the Velop nodes must be added as secondary nodes.


1.  What are the requirements for setting up the Linksys MR8300?

Below are the requirements for setting up the Linksys MR8300:
  • Internet connection
  • Mobile device for setup:
    • iOS 9.0 and later
    • Android™ 4.1 and later
  • Linksys app 2.7.8 or later for setup

2.  How do I set up the Linksys MR8300?

Setting up the Linksys MR8300 is easy using the Linksys app.  To know how, click here.

3.  Can I add the Linksys MR8300 as a secondary node to my existing Velop network?

No.  The Linksys MR8300 can be only be set up as a primary node.  If you have existing Velop devices on your network, such as the WHW03, you will need to reset it and add it as a secondary node.

You may use the following links for instructions:

Setting up the Linksys MR8300
Resetting your node
Adding a node to your existing Velop system

4.  When can I use the WPS button?

The WPS button is functional after the Linksys MR8300 is set up.  Once your Mesh router is set up, you can press on the WPS button to connect client devices that support WiFi Protected Setup™ (WPS).


1.  How do I access the Linksys MR8300 dashboard?

Step 1:
Connect your mobile device to your Linksys MR8300's Wi-Fi and Launch the Linksys app.

Step 2:
Tap the Log in button.

Step 3:
Enter your email address and app password and tap Log in (to log in via the internet).  To access it directly (not over the internet), tap the Use Admin Password tab and enter your credentials.  After logging in, the app will take you to the dashboard.

2.  How do I connect to the Wi-Fi using the WPS PIN?

To connect to the Wi-Fi using the WPS PIN, follow the steps below:

Step 1:
Launch your Linksys app and access your Linksys MR8300 dashboard.
Step 2:
Tap the Menu icon and then select Wi-Fi Settings.
Step 3:
Tap Connect a Device With WPS.

Step 4:
Tap the Use a PIN link.

Step 5:
You can either enter your device's WPS PIN in the field provided and tap Connect or if your device asks you for the router's WPS PIN, use the PIN shown on the WPS page.


1.  How can I reset the Linksys MR8300 to factory defaults?

To reset the Linksys MR8300 to its factory defaults, press and hold the reset button until the light goes out and then turns bright red.  To learn more, click here.

2.  Why am I instructed to connect to my router's setup Wi-Fi?

This happens when the Bluetooth® was not established or the Bluetooth of the device used in setting up is not turned ON.  To continue
, follow the steps below:

Step 1:
Take note of the Wi-Fi name and password that can be found on the label under the Linksys MR8300.

Step 2:
On your device, go to Settings and connect to the Wi-Fi name from Step 1.

Step 3:
Return to the Linksys app.

3.  Why am I instructed to provide my ISP credentials?

You will be instructed to provide your ISP credentials if a Point-to-Point Protocol over Ethernet (PPPoE) connection is detected during setup.  If PPPoE fails, you will be prompted to continue setup without an internet connection.  You can either continue or contact your ISP to verify your PPPoE information.


1.  How do I add a node?

For instructions on how to add a node, click here.

2.  What is Bridge Mode?

Bridge Mode allows you to use your Linksys MR8300 to extend your existing network.  If you have an existing router or modem-router (gateway) and you want to continue using your main router, you can enhance your Wi-Fi network using the Linksys MR8300 with the Velop system.

3.  How do I set up the Linksys MR8300 as Bridge Mode?

To know how to set up your Linksys MR8300 with the Linksys app, click here.

Once your Linksys MR8300 is set up and running, you can then change the Connection Type to Bridge Mode using the Linksys app.  For instructions on how to do this, click here.

4.  What features are disabled when the Linksys MR8300 is in Bridge Mode?

Device List, Speed Check, Parental Controls, Device Prioritization, Port Forwarding, and Wi-Fi MAC Filters are not supported when your Linksys MR8300 is in Bridge Mode.

5.  If I have nodes connected to the Linksys MR8300, do I need to change them all to Bridge Mode as well?

No.  Since the Linksys MR8300 acts as the primary node; after you choose the Bridge Mode option, all your nodes will be in Bridge Mode.
