IP Passthrough mode setup for AT&T U-verse®

If you have AT&T U-verseĀ® services, you are required to use the gateway combo equipment supplied to you.Ā  The simplest solution to using the Velop system with U-verse is setting your gateway in IP Passthrough mode.Ā  Due to the nature of U-verse and the necessary requirements, it has to pass traffic on your network and setting your gateway in IP Passthrough mode will allow you to get all the same benefits of the Linksys Velop Intelligent Mesh Wi-Fi System while allowing U-verse to continue to manage all your networkā€™s routing.

Directions

To put your gateway in IP Passthrough mode, first connect your laptop or computer to the gateway.Ā  Then, connect Velop to your gateway.
Ā
Step 1:
Open a web browser and enter the IP address of your gateway located at the back label (ex. 192.168.1.254).Ā  Log in to the web-based setup page using the Access Code which you can find on the label of your gateway.

User-added image

Step 2:
Select Firewall and click IP Passthrough.

User-added image

Step 3:
On the Allocation Mode section, select Passthrough from the drop-down menu.

User-added image

Step 4:Ā Ā Ā
Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā
Select DHCPS-fixed from the drop-down menu in Passthrough Mode.Ā  Then, on the Manual Entry section, enter the MAC address of the Velop system's primary node which you hardwire with AT&T's gateway.Ā  Click the Save button to complete the setup.

User-added image

NOTE: Ā You can find the MAC address from the bottom label of the Velop node.

User-added image

You're almost done!

Once you're done setting up the gateway, you may nowĀ  proceed in installing your Velop system.
